The dispersion angle of each speaker’s horn is optimised for its intended use. The LINEAR 9 110 XA 10" speaker is equipped with an 80° x 60° wide dispersion horn for homogeneous near-field dispersion. It can be rigged either via the rigging points (steel cables or chains in combination with the AP-8 attachment point) or with the TB-28N tilt bracket.

• Max. SPL @ 10% THD: 126 dB half space (70 Hz – 12 kHz averaged)
• Max. SPL peak @ 10 % THD: 129 dB half space
• Frequency response +/-3 dB: 70 Hz – 19 kHz
• Frequency response -10 dB: 65 Hz – 20 kHz
• Power amp output (RMS): 700 W
• Amp type: Class D - biamped
• LF driver: N/A
• Low-/mid speaker: 1x 10", 2.5" voice coil
• HF driver: 1", 1.4" voice coil
• Horn directivity: 80° x 60° CD horn, rotatable
• Active crossover frequency: 2 kHz FIR X-over with 60 dB/oct.
• Maximum input level: +20 dBu
• Analog inputs: 1x XLR combo balanced
• Analog thru: 1x XLR balanced
• DSP Out: 1x XLR balanced
• Network port: Ethercon RJ45, 1x In, 1x Thru
• Filter presets: Flat, Monitor, Low Cut, Remote
• Remote software: DSP CONTROL (Windows, macOS)
• DSP functions: Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
• Sample rate: 96 kHz
• System latency: Less than 2.6 ms
• Mains connector: 1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V
• Power consuption: 1 A / 100–240 V nominal according to EN 62368-1
• Clustering angle: N/A
• Angles up (Monitor angle): 30°
• Pole mount: DuoTilt 3°/7°
• Rigging points: 5x M8 (AP-8)
• Carrying handles: 2x SingleGrip
• Housing: Birch multiplex
• Finish: PU coating black
• Front grille: 2 mm metal grille backed with black acoustic foam
• Dimensions (WxHxD): 36 x 54 x 31 cm 14-11/64 x 21-1/4 x 12-13/64"
• Weight: 16.5 kg / 36.4 lbs
